    Recycling Corrugated Roof Sheet Making Machine Building Material 250-400kg/Hour

    Ask Lasest Price
    Brand Name : Acemien
    Model Number : SJZ80/156
    Certification : CE ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 300sets/year
    Delivery Time : 45 working days
    • Product Details
    • Company Profile

    Recycling Corrugated Roof Sheet Making Machine Building Material 250-400kg/Hour

    Recycling Machine Corrugated roof sheet Building Material Making Machinery


    Application:


    Roof tile and resin tile can be high-grade plants, steel factories, warehouses, farm market, market access, sheds and other high-end roofing materials. Especially in corrosive chemical plants, smelters, ceramic plants, soy sauce factory, chemical plants, printing and dyeing plant, organic solvent factory, acid, alkali and other corrosive plant.

    3 layer Heat Insulated UPVC Roof Sheet is manufactured based on 3 layer co-extrusion technology by one-time processing. It is an ideal building material for construction projects with heat insulation requirement. The following is a list of the distinct features of each layer material.


    First layer:weather resistant resin is selected as the top layer material to block the solar ultraviolet radiation and reduce the coefficient of heat conductivity. It provides our UPVC roofing material with great durability and chemical corrosion resistance;


    Second layer:the middle layer is a special foam structure with heat and sound insulation performances.


    Third layer:the bottom layer of our heat insulated UPVC roof sheet adopts modified PVC material to offer optimum strength and rigidity.



    Machine configuration:


    No.MachineQty.
    1Screw loader for extruder1setCorrugated tile extrusion line

    Ridge tile forming machine
    2Conical twin-screw extruder(PVC)1set
    3Vacuum loader and drying hopper1set
    4Single screw extruder(ASA)1set
    5Extrusion mould and distributor1set
    1set
    7Temperature controller1set
    8Corrugated-tile forming machine1set
    9Cutter1set
    10Stacker1set
    11Ridge tile Oven1set
    12Ridge tile Forming machine and ridge tile mould4set
    13Screw loader for Mixer1setAuxiliary equipment
    14Mixer unit1set
    15Crusher1set
    16Pulverizer1set

    Raw material & formulationPVC resin, Caco3, lubricant,stabilizing agent, pigment, anti-ultraviolet agent etc.
    Central height:1000mm
    Max. Haul-off speed:0.3-4m/min
    Operation directionFrom right to left (face to the operation panel)
    Machine colorBlue or as per your request
    Description final product & Output capacity

    Single layers UPVC Roofing tile;

    Width:880 or 1050mm,Thickness: 2~4.0mm;

    Wave distance:180mm; Wave height:30mm;

    Output:200-350kg/h(Depending on CaCO3 proportion)





    Our factory and workshop
