Discount plastic ceiling panel tile sheet board extruder production
line
Plastic PVC ceiling wall panel making machine is aslo called PVC
ceiling panel production line,PVC ceiling panel extrusion
machine,which is used to make different shape of PVC ceiling
panel,PVC wall panel.The width of final PVC ceiling can be
15cm,20cm,25cm,30cm and 60*60cm.The surface of PVC ceiling panel
can be treated by printing,hot hot stamping or lamination.
Main features :
* Extruder flange adopts hinged type, convenient for changing
filtration net, reduce time for changing net.
* Speed controlled by inverter, saving power and easy to adjust
speed
* Extruder temperature controlled by Omron intelligent controller,
temperature fluctuation self adjusting
* Easy and convenient for operation and maintain
* Low power consumption
* Economical price, suitable for large scale investment.
The main machines needed for PVC wall panel:
-PVC mixer
-PVC panel extrusion line
(Including autoloader, conical twin screw extruder, mould, vacuum
calibration chamber, hauling machine, auto cutter- stacker)
- hot stamp printer or two color printing line or lamination
- PVC crusher& PVC miller
- Air compressor
- Water chiller (optional)
| Model | Max wide(mm) | Extruder model | Max output(kg/h) | Drive motor power(kw) |
| SJZ108 | 108 | SJZ51/105 | 100 | 18.5 |
| SJZ180 | 180 | SJZ51/105 | 100/150 | 18.5/22 |
| SJZ240 | 240 | SJZ65/132 or SJZ55/110 | 250 | 37 |
| SJZ300 | 300 | SJZ65/132 | 250 | 37 |
| SJZ400 | 400 | SJZ80/156 | 350 | 55 |
| SJZ500 | 500 | SJZ80/156 | 350 | 55 |
| SJZ600 | 600 | SJZ80/156 | 400 | 75 |
| Products | PVC ceiling, PVC panel, PVC wall panel |
| Specification | Proof | Light in weight and easy installation |
| Unit price | US1.50~US4.00 |
| Caco3 Ratio | 30-200% |
| Width | 10cm/16cm/18cm/20cm/25cm/30cm/60cm |
| Length | 5.8m/5.95m/as customers' requirements |
| Thickness | 6mm/7mm/7.5mm/8mm/9mm/10mm/11mm/12mm |
| Weight | 1.85kg-3.3kg |
| Surface | Printing, hot-stamping, pearlite printing, peritoneal, normal
glossy, high glossy |
| Colors | Varied colors to you choose |
| Features | (1)High shrink surface, smooth without gap when concatenated |
| (2)Fireproof, moisture-proof, mould-proof, waterproof, soundproof,
sound-absorbing, light in weight and easy installation |
| (3)For ceiling and wall decoration |
| (4)The variety of colors and patterns |
| Type | Flat surface or middle groove |
FAQ
1.Q: Are you manufacture factory or a trader?
A: We are an industrial manufacture factory of plastic extrusion
machinery for years, which locates in Zhangjiagang city, China.
2.Q: What's your payment term:
A:T/T 30% in advance & T/T 70% upon sending the copy of Bill of
Lading, L/C 100%, or negotiate according to the order status.
3.Q: Can we visit your factory ?
A: Warmly welcome. Once we have your schedule, we will arrange the
professional sales team to follow up your case
4. Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients
should be satisfied first.
5.Q:Do you have any after-sale service ?
A:Yes,we have professional after-sale teamwork . any technical
question could be solved in 24 hours by our after-sale teamwork.
6.Q:How do you install your equipment in our factory ?
A:We have professional after-sale &installation teamwork, we
will arrange our engineer fly to ur factory install and teach ur
labor .
our exhibition :
